Static analysis of frames and trusses

Static-Dynamic analysis of frames and trusses

This application uses a highly flexible, general, finite element method for static and dynamic analysis of multi span beams, 2D Trusses and 2D Frames.It features a versatile-easy interface and the most reliable finite element calculation library.It features a powerful, interactive and easy interface.Its simple interface results into time saving while modeling and analyzing any type of static system.Static and dynamic analysis in a couple of mins!

Use of highly flexible, general, finite element method

Static and dynamic analysis of multi span beams, 2D trusses and 2D frames

Modal analysis and eigenvalues estimation

User controlled damping coefficient

Mode superposition method in order to calculate the dynamic response

Automatic creation of consistent mass matrix (Engissol’s patent)

Multi-step dynamic analysis which is fully customized

User controlled step and time parameters

Definition of time-dependent loading on elements and nodes

Unlimited number of Nodes and Beams

3 Degrees of freedom per Node, 6 per Beam

Supports all major measure units

All type of boundary conditions (fixed, rollers, etc.)

Translational and rotational spring supports

Prescribed displacements and speeds

Extreme

We challenge you to try out this frame analysis program, as there are other analysis programs out there, but you will convince yourself that Engissol Frame 2D is unique because of its features and the ease in using it.

Civil and Structural Engineers, Students, Researchers, Mechanical Engineers
